V2 - Hybrid Coating 50ml
DESCRIPTION
An unique formulation that combines the high purity nano ceramic coating and high quality Nano Titanium. Its blend of inorganic materials create a hard protective barrier with superior hydrophobic effect.
It protects the paint surface from dirt, acids, UV rays and scratches for up to 2 years.
PROPERTIES
- Super hydrophobic effects
- High gloss finish
- 7H pencil hardness
- Easy-to-Clean
- UV and chemical resistance
- Easy to apply
- Cures at room temperature
APPLICATION
Hybrid Coating is particularly suitable for car painted surfaces, such as one (1K) or two component (2K) paints (polyurethane or epoxy systems). The preferred use is for the exterior paint of cars, motorbikes, trucks, and buses
TOOLS
Depending on the substrate Hybrid Coating can be applied with microfiber applicators. The product is also suitable for spray application.
Spray application:
Process: HVLP-compressed air
Spray gun: e.g. SATA minijet HVLP
Working pressure: ca. 2 – 3 bar
Nozzles: 0.8 – 1.3 mm
The spray gun can be cleaned with n-butyl acetate, for example.
TECHNICAL DATA
Appearance: Colourless
Density: ca. 0,76 g/cm3
Base: Polysiloxane
Curing: Normal ambient temperature/ 80° celcius
Shelf Life: 12 months
Container Size: 50ml
INSTRUCTIONS FOR USE
The product is for professional use and should be applied by approved applicators only. Test on a small area or apply a test coat before application.
APPLICATION OF V2 HYBRID COATING
Shake well before use.
Get ready with 3 pieces of brand new, lint-free microfiber towel. (It is recommended that new towels to be rinsed or washed with water prior to use to reduce the loosing lint)
When first applying V2 Hybrid Coating on substrate, it is recommended to condition the surface of the applicator block with 7-8 drops to prevent skipping or dry spots.
Do not work on large area at a time. It is recommended to do a 2 ft. x 2 ft. area at a time.
Apply V2 Hybrid Coating using normal pressure on applicator. Make sure the area is well covered. Always start from an edge to avoid excess on other panels. Work in controlled areas to remember where you previously applied. Work in horizontal or vertical movements to ensure that product is carried through consistently.
Wait for 1-2 minutes. Use first towel to level the product.
Go immediately over with second microfiber towel with polishing motion until the surface is free from residue.
Follow by the third towel (this is called the “insurance towel”) and go over the surface one extra time just to make sure you haven’t miss any streaks or excess residue just to make sure you haven’t miss any streaks or excess residue.
When the whole car is applied, allow curing of coating to begin. Wait approximately 30-60 minutes before applying a second layer. For the ultimate in hydrophobic results and durability, it can be over-coated with V1 3D Matrix Coating (Top).
Curing times depend on temperature and humidity. Applying too early and the product will dissolve the previous layer. Allow curing of coating to begin. Curing can be accelerated using IR Lamps. Follow lamp manufacturer's recommended settings.
Keep coating away from all polish and compound dust during curing process.
INSPECTION LIGHTING SYSTEM
Lighting is utmost important during application of coating to paint. Spot Light like Scangrip is a good lighting system to inspect paint defects during polishing but in fact it is NOT RECOMMENDED to use to check the reside of coating left on paint. The suitable lighting system is Diffused Light.
INSTRUCTION VIDEO
PROCESSING & CURING
Product must be applied at an ambient temperature of at least + 5°C and a relative humidity of 30 % - 80 %. Avoid direct sunlight! Apply the coating in dry conditions. Any mistakes can be rectified within approx. 10 min of application. Traces of water in the applicator should also be avoided. Applicators dampened with water should not be used. The applicators cannot be reused once the coating has been applied. Hybrid Coating is dry-to-touch after about one hour.
The recommended curing conditions (until water resistant) are:
- Room temperature: 8 – 12 hours
- 80 °C (Infra-red curing): 2 hours
Curing can be accelerated by using IR Lamps after V1 Top is applied. Heating Polysilazanes results in crosslinking to form higher molecular weight polymers. Recommended settings for IR lamps are as following:
i. Minimum 80cm of distance above the surface.
ii. Maximum 80⁰C of surface temperature.
iii. Maximum 30 minutes on each panel.
The Hybrid coating is fully effective after 5 – 7 days’ curing at room temperature. During this time, the vehicles should not be driven into a vehicle wash.
